Specification

Volts：12

Kilowatts (kw)：1.4

Overall Length (mm)：195

Mounting Hole (mm)：1x10xM8x1.25

Mount Hole Centres (mm)：102

Flange Diameter (mm)：70

Nose Cone Length (mm)：60

Pinion At Rest (mm)：28

Field Housing Diameter (mm)：70

Teeth：8TH

Rotation：CW

Pinion Diameter (mm)：28

Fitment

Fit For Suzuki Alto GF incl.: GL, GLX 3 cyl K10BN 1.0L 996cc 2009-2014

Fit For Suzuki Baleno EW incl.: GLX Turbo 3 cyl K10C 1.0L 996cc 2016-2019

Fit For Suzuki Kizashi FR engine J24B 2.4L Petrol 2010-2016

Fit For Suzuki Swift FZ ZC82S NZ engine K14B 1.4L Petrol 2013-2017

Fit For Suzuki Grand Vitara JB424 engine J24B 2.4L Petrol 2008-2019

Fit For Suzuki Grand Vitara JB JE JD JT engine J24B 2.4L Petrol 2008-2019

Fit For Suzuki SX4 GY EY RW420 engine J20B 2.0L Petrol 2010-2019

Package

1 x Starter Motor
