Specification

Volts：12

Kilowatts (kw)：2.0

Overall Length (mm)：220

Mounting Hole (mm) ：13/M12x1.25

Mount Hole Centres (mm) ：127

Flange Diameter (mm)：82

Nose Cone Length (mm) ：NA

Pinion At Rest (mm)：18

Field Housing Diameter (mm)：70

Teeth：10TH

Rotation：CW

Pinion Diameter (mm)：37

Fitment

Fit For Toyota  Fortuner GUN156R  2.8L 4cyl Diesel - 1GD-FTV  08/2015 - ON

Fit For Toyota  Granvia  GDH303R    2.8L 4cyl Diesel - 1GD-FTV    07/2019 - ON

Fit For Toyota  Hiace  GDH300R    2.8L 4cyl Diesel - 1GD-FTV    01/2019 - ON

Fit For Toyota  Hiace  GDH320R    2.8L 4cyl Diesel - 1GD-FTV    01/2019 - ON

Fit For Toyota  Hilux  GUN122R    2.4L 4cyl Diesel - 2GD-FTV    01/2015 - 12/2019

Fit For Toyota  Hilux  GUN123R    2.8L 4cyl Diesel - 1GD-FTV    01/2015 - 12/2017

Fit For Toyota  Hilux  GUN125R    2.4L 4cyl Diesel - 2GD-FTV    01/2015 - ON

Fit For Toyota  Hilux  GUN126R    2.8L 4cyl Diesel - 1GD-FTV    01/2015 - ON

Fit For Toyota  Hilux  GUN136R    2.8L 4cyl Diesel - 1GD-FTV    01/2015 - ON

Fit For Toyota  Landcruiser Prado  GDJ150R    2.8L 4cyl Diesel - 1GD-FTV    06/2015 - ON

Package

1 x Starter Motor
